How dense is titanium? Pure titanium has a density of 4.506 g/cm3 (4,506 kg/m3) at room temperature. In US units, that is about 0.163 lb per cubic inch or 281 lb per cubic foot. The common alloy Ti-6Al-4V (Grade 5) is slightly lighter, at about 4.43 g/cm3 (0.160 lb/in3).

How dense is titanium: 4.506 g/cm3 for pure titanium, about 0.163 lb per cubic inch

As an Amazon Associate, Measuring Expert earns from qualifying purchases.

Titanium has a reputation as the “light but strong” metal, and the numbers back that up. It is about 42% lighter than steel for the same volume, yet roughly 67% heavier than aluminum. As a result, that middle position, combined with high strength and excellent corrosion resistance, explains why it shows up in jet engines, hip implants, bike frames and watch cases.

The Royal Society of Chemistry lists the density of titanium as 4.506 g/cm3 for the pure element. However, most titanium you can buy is either commercially pure (Grades 1 to 4) or an alloy. For example, an alloy maker’s data sheet gives 0.16 lb/in3 for Ti-6Al-4V, which works out to about 4.43 g/cm3. Therefore, the exact figure depends on what you are holding.

Convert Titanium Density to lb/in3, lb/ft3 and More

The converter starts at 4.506 g/cm3, the value for pure titanium. Type a different number, such as 4.43 for Grade 5, or switch the starting unit. It then shows the same density in every other metric and US unit.

How Dense Is Titanium in Every Common Unit?

Every value below starts from 4.506 g/cm3 and uses the exact NIST definitions of the inch, pound and gallon. In addition, the last column turns each number into something you can picture.

UnitPure titaniumWhat it means
g/cm3 (same as g/mL)4.506A 1 cm cube weighs 4.5 g
kg/m34,506A 1 m cube weighs about 4.5 metric tons
kg/L4.5061 liter of titanium weighs about 9.9 lb
lb/in30.1628A 1 in cube weighs about 2.6 oz (73.8 g)
lb/ft3281.3A 1 ft cube weighs about 281 lb (127.6 kg)
lb/US gal37.60A gallon of titanium would weigh about 17.1 kg

You can also flip the numbers around. One pound of pure titanium fills about 100.7 cm3, or 6.14 cubic inches. That is a block about the size of a deck of playing cards.

Note: Engineers in the US usually quote titanium as 0.163 lb/in3 (pure or commercially pure) or 0.160 lb/in3 (Grade 5). If a drawing lists 0.16 lb/in3 without a grade, it is most likely Ti-6Al-4V.

How Dense Is Titanium by Grade and Alloy?

The word “titanium” covers several materials. For instance, commercially pure grades are almost all titanium, so they sit very close to 4.51 g/cm3. Alloys, on the other hand, mix in other elements. Aluminum is lighter than titanium, while vanadium and molybdenum are heavier, so the final density shifts a little either way.

MaterialTypical useDensity (g/cm3)Density (lb/in3)
Pure titanium (element)Reference value4.5060.163
Grade 1 to 4 (commercially pure)Chemical plants, marine parts, some implantsabout 4.510.163
Grade 5 (Ti-6Al-4V)Aerospace, bike parts, implants, fastenersabout 4.430.160
Grade 9 (Ti-3Al-2.5V)Bike frames, tubingabout 4.480.162

Grade 5 is the alloy most people mean when they say “titanium” on a product label. In addition, it holds about 6% aluminum and 4% vanadium by weight. Because aluminum is much lighter, the alloy ends up about 1.7% less dense than the pure metal. Even so, in practice that difference is too small to feel in the hand.

How Dense Is Titanium Compared With Steel and Aluminum?

This is the comparison most readers want, because titanium sits neatly between the two everyday structural metals.

How dense is titanium by grade and alloy
MetalDensity (g/cm3)lb/in3Compared with titanium
Aluminum (pure or 6061)2.700.098Titanium is about 1.67 times denser
Titanium (pure)4.5060.163–
Carbon steelabout 7.850.284About 1.74 times denser than titanium
304 stainless steelabout 8.000.289About 1.78 times denser than titanium
Copper8.960.324About twice as dense as titanium
Lead11.340.410About 2.5 times denser than titanium
Tungsten19.250.695About 4.3 times denser than titanium

So a titanium part weighs about 57% of an identical steel part. However, it weighs about 1.67 times as much as the same part in aluminum. The reason designers still pick titanium over aluminum is strength: Grade 5 has an ultimate tensile strength of roughly 131,000 psi (about 900 MPa), far above common aluminum alloys. As a result, a titanium part can often be made thinner, and the finished piece can end up lighter than the aluminum version.

For the heavy end of the scale, see our guides on how dense lead is and how dense tungsten is. By contrast, tungsten packs more than four times as much mass into the same space.

Why Titanium Has a Low Density for a Strong Metal

A metal’s density comes down to two things: how heavy each atom is and how tightly the atoms pack. First, titanium atoms are light. Its standard atomic weight is about 47.87, compared with about 55.85 for iron and 183.8 for tungsten. In addition, titanium atoms are fairly large for their mass, so fewer of them fit in each cubic centimeter.

At room temperature titanium has a hexagonal close-packed crystal structure, often called the alpha phase. However, above about 882 C (1,620 F) it changes to a body-centered cubic beta phase. Alloying elements such as aluminum and vanadium are chosen partly to control which phase forms, which is how metallurgists tune strength and toughness.

Recommended Tools for Checking Titanium Density

To find a density yourself, you therefore need mass and volume. First, a pocket scale that reads to 0.01 g handles small parts such as screws and rings. Next, a glass graduated cylinder measures volume by water displacement. Finally, a digital caliper measures regular shapes such as bars, plates and tubes, so you can calculate volume directly.

How to Measure How Dense Titanium Is at Home

Water displacement works for any solid piece that fits in a cylinder, such as a bolt, a ring or an offcut. Also, it is a simple way to check whether a “titanium” item is genuine.

Measuring how dense titanium is at home
  1. Weigh the part. Place the dry piece on a scale that reads to 0.01 g and note the mass in grams.
  2. Fill a graduated cylinder partway. Add enough water to cover the part, then read the level at eye height.
  3. Slide the part in gently. Tilt the cylinder and let the metal slide down the wall so it does not crack the glass.
  4. Read the new level. Subtract the first reading from the second; the difference in mL equals the volume in cm3.
  5. Divide mass by volume. For example, 45.1 g divided by 10.0 mL gives 4.51 g/cm3.
  6. Convert the result. Enter your figure in the converter above to see it in lb/in3 or lb/ft3.
Tip: Test at least 30 to 50 g at once. A 0.5 mL reading error on a 5 mL part is a 10% error, which is enough to confuse titanium with aluminum-coated steel. Similarly, tap the cylinder to knock off air bubbles before you read the level.

Do and Don’t for Accurate Density Readings

Do

  • Dry the part fully before you weigh it.
  • Read the water level at the bottom of the curve.
  • Use the smallest cylinder the part fits in.
  • Repeat the test two or three times and average.
  • Compare your result with the grade you expect.

Don’t

  • Test hollow tubes or parts with sealed cavities.
  • Ignore coatings, plating or plastic inserts.
  • Drop heavy parts straight into thin glass.
  • Trust a single reading on a very small piece.
  • Assume a gray, light metal must be titanium.

Density, Specific Gravity and Strength-to-Weight

Three related ideas often get blended together when people talk about titanium. So here is how they differ.

TermWhat it meansValue for titanium
DensityMass per unit volume4.506 g/cm3, 0.163 lb/in3
Specific gravityDensity divided by the density of water (no units)About 4.5
Strength-to-weight ratioStrength divided by densityVery high for Grade 5, which is why aircraft use it

In short, density belongs to the material, while weight belongs to the object. For a refresher on that difference, see what mass is and how it is measured.

How Dense Is Titanium Really? Honest Limits

The 4.506 g/cm3 figure describes pure, solid titanium near room temperature. However, real parts differ for several reasons. First, alloys shift the value, so Grade 5 reads about 4.43. Second, 3D-printed and powder-made parts can hold tiny pores, which make them read light. Third, heat expands the metal slightly; at 100 C (212 F) the density drops by only about 0.2%. Finally, home tests carry error from the scale, the cylinder markings and trapped air.

Therefore, a home result between about 4.3 and 4.6 g/cm3 is consistent with titanium or a titanium alloy. On its own, though, it cannot tell you the grade. Reference books also round differently, so you will see 4.5, 4.506 and 4.51 quoted for the same metal.

When Accuracy Really Matters

For a ring or a bike part, for example, a rounded figure is fine. In other settings the exact grade and certified data matter far more than a home test:

  • Aerospace and engineering. For this reason, weight and stress calculations should use the density from the mill certificate or the material specification, not a general table.
  • Medical implants. Similarly, implant materials follow strict standards, and only the manufacturer can state what a device is made of.
  • Machining and welding. Fine titanium chips and dust can burn. Follow the machine maker’s and OSHA safety guidance, and keep chips cleaned up.
Warning: Titanium fines and turnings can ignite, and burning titanium should not be fought with water. Instead, store chips in closed metal containers and follow your shop’s fire safety plan.
Disclaimer: This article is general information about the density of titanium. It is not engineering, medical or safety advice. Use certified material data for design work, and ask a qualified engineer or your doctor about specific parts or implants.

Frequently Asked Questions

How dense is titanium in g/cm3?

Pure titanium has a density of 4.506 g/cm3 at room temperature, which equals 4,506 kg/m3 or 4.506 g/mL.

How dense is titanium in lb/in3?

Pure titanium is about 0.163 lb per cubic inch. Grade 5 (Ti-6Al-4V) is about 0.160 lb per cubic inch.

What is the density of Ti-6Al-4V?

Ti-6Al-4V, also called Grade 5, has a density of about 4.43 g/cm3, or 0.160 lb/in3, slightly lower than pure titanium.

How dense is titanium compared with steel?

Titanium is about 42% lighter than carbon steel for the same volume. Steel is about 7.85 g/cm3, while titanium is 4.506 g/cm3.

How dense is titanium compared with aluminum?

Titanium is about 1.67 times denser than aluminum, which is about 2.70 g/cm3. However, titanium is much stronger.

How much does a cubic inch of titanium weigh?

A 1 inch cube of pure titanium weighs about 73.8 g, which is about 2.6 ounces or 0.163 lb.

How much does a cubic foot of titanium weigh?

A cubic foot of pure titanium weighs about 281 lb, which means about 127.6 kg.

Does titanium float on water?

No. Because titanium is about 4.5 times denser than water, a solid titanium part sinks quickly.

How can I tell if something is real titanium?

Measure its density by water displacement. A result near 4.4 to 4.5 g/cm3 fits titanium, while steel reads near 7.9 and aluminum near 2.7.

Why is titanium used in aircraft if aluminum is lighter?

Titanium alloys are far stronger and handle heat better, so parts can be thinner. As a result, titanium often wins on strength-to-weight and in hot engine areas.

How Dense Is Titanium? The Bottom Line

To sum up, pure titanium has a density of 4.506 g/cm3, which is 4,506 kg/m3, 0.163 lb/in3 or 281 lb/ft3. Meanwhile, Grade 5 (Ti-6Al-4V) comes in a little lower at about 4.43 g/cm3. That makes titanium about 42% lighter than steel but about 67% heavier than aluminum.

If you test a part yourself, a result in the 4.3 to 4.6 range points to titanium. For anything structural or medical, though, rely on certified material data. Finally, use the converter at the top of this page whenever you need the number in another unit.
